Big Creek, Florence Lake Dam

Description
Big Creek, Florence Lake Dam - Record photo of core samples taken from extrados of Arch #9 during October 1943. Reading from left to right 9-5, 9-4, 9-3, 9-2, and 9-1.
Type
Visual Materials(Opens in new tab)
Date
11/12/1943
Call number
photCL SCE 02 - 24888
