Big Creek, Huntington Lake Dams - Dam 1

Description: Big Creek, Huntington Lake Dams - Dam 1 - Cracking and back seepage on unreinforced gunite.
Type: Visual Materials(Opens in new tab)
Date: 4/3/1942
Call number: photCL SCE 02 - 24560
Find out more: View in the Huntington Digital Library(Opens in new tab); View in the Library catalog(Opens in new tab)
