Big Creek, Florence Lake Dam

Description: Big Creek, Florence Lake Dam - Day's Work Joint Repair April 1940. Chipping seams on Arches #40 & 41.
Type: Visual Materials(Opens in new tab)
Date: 4/21/1940
Call number: photCL SCE 02 - 22872
Find out more: View in the Huntington Digital Library(Opens in new tab); View in the Library catalog(Opens in new tab)
