Visual Materials

Big Creek, Florence Lake Dam

Description: Big Creek, Florence Lake Dam - Location of D-7-1, on intrados Arch 7
Type: Visual Materials(Opens in new tab)
Date: 7/28/1939
Call number: photCL SCE 02 - 22743
Find out more: View in the Huntington Digital Library(Opens in new tab); View in the Library catalog(Opens in new tab)
