Big Creek, Huntington Lake Dams - Dam 1 Upstream face

Description: Big Creek, Huntington Lake Dams - Dam 1 Upstream face - Approx. stationing 10+60 to 11+10. Applying steel reinforcing to chipped area near west end prior to guniting.
Type: Visual Materials(Opens in new tab)
Date: 11/30/1939
Call number: photCL SCE 02 - 22492
Find out more: View in the Huntington Digital Library(Opens in new tab); View in the Library catalog(Opens in new tab)
