Visual Materials
Big Creek, Huntington Lake Dams - Dam 3 Upstream face north end prior to backfilling.
photCL SCE 02 - 22486
Visual Materials
Big Creek, Huntington Lake Dams - Upstream of face looking North after completion of concreting and grouting.
photCL SCE 02 - 23633
Visual Materials
Big Creek, Huntington Lake Dams - Dam 3 Upstream face south end prior to backfilling.
photCL SCE 02 - 22484
Visual Materials
Big Creek, Huntington Lake Dams - Copy of Page 8 of Stone & Webster Report on Backfills on Dams at Huntington Lake: 23. Dam 3. Typical chipped out vertical contraction crack before guniting. 24. Dam 3. Chipped out vertical & horizontal cracks near north end. 25. Dam 3A. Excavation at upstream face and water test of old drill hole 12 in progress. 26. Dam 3A. Looking south from station 0+25. Upstream cut off wall during excavation.
photCL SCE 02 - 21851
Visual Materials
Big Creek, Huntington Lake Dams - Dam #3 - Right end of upstream face of dam kept dry by gunite eave.
photCL SCE 02 - 28850
Visual Materials
Big Creek, Huntington Lake Dams - Dam 1 Upstream face - View west from Station 5+25 showing drilling operations along upstream toe.
photCL SCE 02 - 22804
