Big Creek Huntington Lake Dams - Murray Co. experimental 4" conduit copied images with captions

Description: Big Creek Huntington Lake Dams - Murray Co. experimental 4" conduit copied images with captions: 1. View of Murray Conduit placed in reverse curve position. In section of auxiliary spillway concrete. 2. Another view of pulling Murray Conduit, placed in concrete section of auxiliary spillway. 3. Pulling Murray Conduit from auxiliary spillway concrete. Note two men on rope tackle pulling it without difficulty. 4.Close-up showing method of clamping pulling hook on ened of Murry Conduit.
Type: Visual Materials(Opens in new tab)
Date: Dec. 1937
Call number: photCL SCE 02 - 20158
Find out more: View in the Huntington Digital Library(Opens in new tab); View in the Library catalog(Opens in new tab)
