Big Creek, Florence Lake Dam
- Description
- Big Creek, Florence Lake Dam - View of intrados of Arch 52, showing vertical cracks etc.
- Date
- 10/24/1925
- Call number
- photCL SCE 02 - 12835
Visual Materials
Daily: 10 A.M.–5 P.M.
Closed on Tuesdays
1151 Oxford Road
San Marino, CA 91108
Visual Materials
Big Creek, Florence Lake Dam - Photo of Intrados of Arch 52 taken during inspection showing distribution of damp areas. Lake elevation 7326.1.
photCL SCE 02 - 24882
Visual Materials
Big Creek, Florence Lake Dam - View of Intrados Arch #52 - top.
photCL SCE 02 - 22108
Visual Materials
Big Creek, Florence Lake Dam - View of Intrados Arch #52 - bottom.
photCL SCE 02 - 22109
Visual Materials
Big Creek, Florence Lake Dam - Looking west at intrados of Arch #52.
photCL SCE 02 - 12837
Visual Materials
Big Creek, Florence Lake Dam - Record photo of typical vertical crack in 1" buffer gunite at base of river section arches. There are approximately 3 such cracks per arch. This particular crack is on Arch 55.
photCL SCE 02 - 24874
Visual Materials
Big Creek, Florence Lake Dam - View of Intrados, Arch #1
photCL SCE 02 - 22021
