Big Creek, Huntington-Pitman-Shaver Diversion

Description: Big Creek, Huntington-Pitman-Shaver Diversion - Proposed woodstave pipeline from Huntington Lake to Shaver Lake. Looking forward across canyon from 231+50 to flag at 234+70, showing loose rock above line and type of draw requiring angle in pipe of trestle.
Type: Visual Materials(Opens in new tab)
Date: 7/30/1924
Call number: photCL SCE 02 - 12317
Find out more: View in the Huntington Digital Library(Opens in new tab); View in the Library catalog(Opens in new tab)
