Big Creek Powerhouse #3

Description: Big Creek Powerhouse #3 - Penstock from anchor #2 to standpipes, showing venturi meters between located between the heavy anchors.
Type: Visual Materials(Opens in new tab)
Date: 3/15/1924
Call number: photCL SCE 02 - 12068
Find out more: View in the Huntington Digital Library(Opens in new tab); View in the Library catalog(Opens in new tab)
