Visual Materials

Miscellaneous Transmission

Description: Miscellaneous Transmission - Shop testing of stranded aluminum sleeve splice for aluminum conductor on the Vincent Transmission Line.
Type: Visual Materials(Opens in new tab)
Date: 4/14/1926
Call number: photCL SCE 02 - 11542
Find out more: View in the Huntington Digital Library(Opens in new tab); View in the Library catalog(Opens in new tab)

You might also be interested in

Miscellaneous Transmission - New method of splicing 220 kVA aluminum cable
Visual Materials
Miscellaneous Transmission - New method of splicing 220 kVA aluminum cable. - Field splice of aluminum conductor on the Vincent T/L; showing the inner steel sleeve which has been completely compressed over the abutting ends of the stranded steel core forming the interior part of the conductor, and the pouring of a corrosion resistant compound, to be followed by an aluminum wrapping and thereafter the aluminum outer sleeve seen at the right edge of the photo which will be slipped over the splice section and compressed to complete the splice.
photCL SCE 02 - 11539
Vincent Transmission line
Visual Materials
Vincent Transmission line - Three reels of6 aluminum conductor ready for simultaneous stringing on Vincent T/L. (Construction road in left and upper center.)
photCL SCE 02 - 11559
Miscellaneous Transmission
Visual Materials
Miscellaneous Transmission - Live Line Tools for repairing damaged conductor strands
photCL SCE 02 - 23462
Miscellaneous Transmission
Visual Materials
Miscellaneous Transmission - Live Line Tools for repairing damaged conductor strands
photCL SCE 02 - 23463
Miscellaneous Transmission
Visual Materials
Miscellaneous Transmission - Live Line Tools for repairing damaged conductor strands
photCL SCE 02 - 23464
Miscellaneous Transmission
Visual Materials
Miscellaneous Transmission - Live Line Tools for repairing damaged conductor strands
photCL SCE 02 - 23465
