Big Creek Huntington Lake Dams

Description: Big Creek Huntington Lake Dams - Thew No. 0 shovel excavating for dam 3A
Type: Visual Materials(Opens in new tab)
Date: 10/2/1917
Call number: photCL SCE 02 - 04774
Find out more: View in the Huntington Digital Library(Opens in new tab); View in the Library catalog(Opens in new tab)
