Big Creek, Florence Lake Dam

Description: Big Creek, Florence Lake Dam - Progress photo of upstream face of spillway drum gates showing chipping and placing of reinforcing mesh partially completed.
Type: Visual Materials(Opens in new tab)
Date: 9/6/1940
Call number: photCL SCE 02 - 22902
Find out more: View in the Huntington Digital Library(Opens in new tab); View in the Library catalog(Opens in new tab)

You might also be interested in

Big Creek, Florence Lake Dam - Replacement of concrete portion of intake structure, N. wier inlet
Visual Materials
Big Creek, Florence Lake Dam - Replacement of concrete portion of intake structure, N. wier inlet - spillway drum gates. Additional column reinforcing in place prior to building forms for concrete. Lower portion covered with mesh will be gunited out to original surface.
photCL SCE 02 - 22906
Big Creek, Florence Lake Dam
Visual Materials
Big Creek, Florence Lake Dam - Progress photo of upstream face of spillway drum gate section showing guniting in progress.
photCL SCE 02 - 22903
Big Creek, Florence Lake Dam
Visual Materials
Big Creek, Florence Lake Dam - View of river section looking N (downstream) from approximately the upstream face of Arch 53, showing heavy reinforcing at junction of Buttresses 53 & 54, with arches 52, 53, & 54 (highest portion of dam), interados form trusses and studding for lower lifts on Arch 54, and counterweighted placing chutes in position for concreting a lift in Buttress 54.
photCL SCE 02 - 12707
Big Creek, Florence Lake Dam
Visual Materials
Big Creek, Florence Lake Dam - View of the upstream side of the Drum Gate Spillway.
photCL SCE 02 - 24174
Big Creek, Florence Lake Dam
Visual Materials
Big Creek, Florence Lake Dam - Gunite checking upstream face of spillway.
photCL SCE 02 - 23973
Big Creek, Florence Lake Dam
Visual Materials
Big Creek, Florence Lake Dam - Upstream face of South Buttress of Spillway.
photCL SCE 02 - 15914
